High Oxygen Delivery Rate | 10L/min |
Hypoxic Delivery Rate | 100L/min |
Voltage | AC220V±22V,50Hz±1Hz AC110V±15V,60Hz±1Hz |
Output Pressure | 20kPa~60kPa |
Sound Level | ≤48db |
Net Weight | 20kg |
Power Consumption | 800VA |
Size | 34.4x30.6x56.5cm |
Oxygen purity at nitrogen port / Altitude(m) | |||||
Flow | Gear 1.0 | Gear 1.5 | Gear 2.0 | Gear 2.5 | Gear 3.0 |
10L | 8.5% / 6700m | 10% / 5700m | 11.5% / 4700m | 13.0% / 3800m | 14.5% / 3000m |
8L | 10.2% / 5600m | 11.4% / 4800m | 12.8% / 3900m | 14.2% / 3100m | 15.5% / 2400m |
6L | 12.7% / 4000m | 13.8% / 3300m | 15.0% / 2600m | 16.2% / 2000m | 17.2% / 1600m |
4L | 14.8% / 2800m | 15.5% / 2300m | 16.2% / 2000m | 17.0% / 1650m | 17.5% / 1450m |
2L | 18.2% / 1100m | 18.5% / 1000m | 18.8% / | 19.3% / | 19.8% / |
Altitude Hypoxic Generator Accessories
Machine | 1 Set | Breathing Bag | 1 Pieces |
Mask with strap | 1 Piece | Bacterial filterfilter | 2 Pieces |
Air delivery tube | 2 Pieces | T-connector | 1 Piece |
